IoT (Internet of Things Integrated) Data Logger with Sensor MFR-NODE: Multifunction Research Node:

• The Multifunction Research Node has been designed to provide flexible communication, sensor and power options.
• The MFR-NODE supports SDI-12 and 2 x dry contact digital inputs as well as optionally 2x differential / 4x single ended analogue inputs. The MFR-NODE supports sensors with higher power requirements; a solar panel can charge either the internal lithium-ion battery or both the node and sensor can be powered by an external 12V system (e.g. battery or mains source). Optional CAT-M1 provide an option for remote installation and in areas outside the range existing LoRaWAN networks. The optional multiconstellation GNSS ensures you won’t lose track of your device.

AD-NODE: For High Resolution Analogue & Digital Sensors:

• The AD-NODE is designed for those requiring precision in their analogue and digital measurements. With a 24-bit ADC, the AD-NODE supports two RTDs, a 0–10V with compressing range and a 4–20mA input. Each of the four dry-contact digital inputs is capable of simultaneously sampling at 1 kHz, with periodic reporting. Settings on the device can be altered remotely via LoRaWAN™ or locally via USB.

S-NODE: SDI-12 Node for Environmental Monitoring:

• The S-NODE has been designed to support the broad suite of SDI-12 based environmental sensors. The S-NODE can support sensors with higher power requirements; a solar panel can charge either the internal lithium-ion battery or both the node and sensor can be powered by an external 12V system (e.g. battery or mains source). The S-Node’s SDI-12 communications can be customised to allow for interfacing with any SDI-12 sensor.
